Engine make | TATA Cummins |
Engine model | 6BT AA 5.9 – 230 (Euro 2) |
Capacity (cc) | 5883 |
Layout | Diesel inline 6 |
Engine type | Turbo intercooled |
Power kw at r/min | 173 @ 2500 |
Torque Nm at r/min | 800 @ 1500 |
Transmission make | TATA |
Transmission model | GBS – 750 |
Transmission type | Synchromesh |
Shift | Manual |
No. of gears forward | 6 |
First gear ratio | 6.58 |
Top gear ratio | 0.77 |
Overall height | 3400 |
Overall length (mm) | 12000 |
Overall width (mm) | 2600 |
Wheelbase (mm) | 6200 |
GVM (kg) | 17900 |
Seating capacity | 65 seats +1 (includes driver) |
GCM (kg) | 21000 |
D/T (kg) | 21000 |
Payload (kg) | 7590 |
Tare – total (T) (kg) | 10310 |
Permissible rear axle weight (kg) | 10200 |
Permissible front axle weight (kg) | 7700 |
Manufacturer’s rear axle weight (kg) | 10200 |
Manufacturer’s front axle weight (kg) | 9000 |
Clutch type | Single |
Diameter (mm) | 380 |
Reduction type | Single |
Final ratio | 5.8547 |
Brakes type | Full air dual |
Front | Drums |
Rear | Drums |
Anti-lock braking-system (ABS) | Yes |
Retarder | Yes |
Fuel tank capacity (Ltrs) | 350 |
Size & ply rating | 315 / 80 R 22.5 |
