Engine make | TATA Cummins |
Engine model | B5.9 E-III |
Capacity (cc) | 5883 |
Layout | Diesel 6 cylinder inline |
Engine type | Water cooled; direct injection; turbo charged |
Power kw at r/min | 154 @ 2500 |
Torque Nm at r/min | 789 @ 1500 |
Transmission make / model | Eaton |
Transmission type | Synchromesh |
Shift | Manual |
No. of gears forward | 6 |
First gear ratio | 7.05 |
Top gear ratio | 0.78 |
Overall height | 2744 |
Overall length (mm) | 9048 |
Max width (mm) | 2474 |
Front overhang | 1515 |
Rear overhang | 2340 |
Wheelbase (mm) | 5195 |
CA – cab to bogie / rear axle (mm) | 0 |
GVM (kg) | 16000 |
V (kg) | 16000 |
GCM (kg) | 21400 |
D/T (kg) | 21400 |
Permissible body & payload (kg) | 10500 |
Tare – total (T) (kg) | 5500 |
Permissible rear axle weight (kg) | 9000 |
Permissible front axle weight (kg) | 7000 |
Manufacturer’s rear axle weight (kg) | 9000 |
Manufacturer’s front axle weight (kg) | 7000 |
Clutch type | Single dry friction |
Diameter (mm) | 380 |
Reduction type | Single |
Final ratio | 5.857 |
Brakes type | Full air dual |
Front | Drum |
Rear | Drum |
Anti-lock braking-system (ABS) | Yes |
