Engine make | TATA Cummins |
Engine model | B235 20 (Euro 2) |
Capacity (cc) | 5883 |
Layout | Diesel inline 6 |
Engine type | Turbo intercooled |
Power kw at r/min | 170 @ 2500 |
Torque Nm at r/min | 814 @ 1500 |
Transmission make | ZF |
Transmission model | ZF 9S1110 |
Transmission type | Synchromesh |
Shift | Manual |
No. of gears forward | 9 |
First gear ratio | 9.48 |
Top gear ratio | 0.75 |
Overall height | 2800 |
Overall length (mm) | 9370 |
Overall width (mm) | 2448 |
Front overhang | 1515 |
Rear overhang | 2170 |
Wheelbase (mm) | 4880 |
CA – cab to bogie / rear axle (mm) | 4055 |
Ground clearance (mm) | 236 |
GVM (kg) | 24000 |
V (kg) | 24000 |
GCM (kg) | 31000 |
D/T (kg) | 31000 |
Permissible body & payload (kg) | 16620 |
Tare – total (T) (kg) | 7380 |
Permissible rear axle weight (kg) | 18000 |
Permissible front axle weight (kg) | 6000 |
Manufacturer’s rear axle weight (kg) | 19000 |
Manufacturer’s front axle weight (kg) | 6000 |
Clutch type | Single |
Diameter (mm) | 380 |
Reduction type | Single |
Final ratio | 6.17 |
Brakes type | Full air dual |
Front | Drums |
Rear | Drums |
Anti-lock braking-system (ABS) | Yes |
Retarder | No |
Fuel tank capacity (Ltrs) | 350 |
Size and ply rating | 11.00R22.5 – 16PR |
